SPECIFICATION :

Model name
Core 1200W Platinum Modular
Main color
the black
Form factor
ATX

Certification
ATX12V version
2.5
80 PLUS certificate
Platinum
Power Factor Corrector (PFC)
active (APFC)

Parameters
Mains input voltage range
100-240 V, 15-7.5 A, 50-60 Hz
Power
1200 watts
Power on the 12V line
1200 watts
Line current +3.3 V
20 A
Line current +5 V
20 A
+12 V line current
100 A
Line current -12 V
0.4 A
Standby current (+ 5V Standby)
3 A

Cables and connectors
Modular cable connection
Yes
Main power connector
24 (20 + 4) pin - 1 pc.
Processor Power Connector (CPU)
8 (4 + 4) pin - 2 pcs.
Graphics card power connector (PCI-E)
6 + 2 pin - 10 pcs.
Number of SATA connectors (15-pin)
9 pcs.
Number of Molex connectors (4-pin)
3 pcs.
Number of Floppy Connectors (4-pin)
1 PC.

Cooling system
A type
active
Fan size
135 mm
