Specification :
- Max. Output Capacity : 550W
- Color : Black
- Dimension : 150mm x 86mm x 141mm
- PFC （Power Factor Correction）: W/Active PFC
- Power Good Signal : “Power Good” signal rise time is within 1ms.
- Hold Up Time : 16msec (minimum) at 80% of Max. load at 115/230 Vac input.
- Input current : 230Vac/7Amax
- Input Frequency Range : 60Hz / 50Hz
- Input Voltage : Only 230V
- Operating Temperature : 5°C to +40°C
- Operating Humidity : To 85% relative humidity
- Storage Temperature : -40°C to +35°C
- Storage Humidity : To 95% relative humidity
- Cooling System : 120mm Fan: 1600-1900 RPM
- Efficiency : 70% typical at nominal line, maximum load.
- MTBF : 100,000 hrs minimum
- Safety Approval : CE, TUV SUD, CB, EAC and RCM certified.
- PCI-E 6+2pin : 6+2pin PCI-E Connector x 2
