THERMALTAKE H330 TG SE

SPECIFICATION :

CA 1R8 00M1WN 00
Series : H Series
Model : H330 TG
CASE TYPE : Middle tower
Dimension (H x W x D) : 419 x 210 x 480 mm (16.5 x 8.27 x 18.9 inch)
NET WEIGHT : 6.12 kg 13.49 lb
SIDE PANEL : 4mm Tempered Glass x1(Left)
Color : Exterior Interior : Black
MATERIAL : SPCC

COOLING SYSTEM
Rear (exhaust) : 1 x 120 x 120 x 25 mm fan (1000rpm, 16 dBA)

Drive Bays
Accessible
Hidden: 2 x 3.5 or 2.5 (HDD Rack) 2 x 2.5 (HDD Bracket)

EXPANSION SLOTS : 7
MOTHERBOARDS : 6.7 x 6.7 (Mini ITX), 9.6 x 9.6 (Micro ATX), 12 x 9.6 (ATX)
I O Port : 1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio,
PSU : Standard PS2 PSU (optional)

FAN SUPPORT
Front:
3 x 120mm or 2 x 120mm or 1 x 120mm
2 x 140mm or 1 x 140mm
2 x 200mm or 1 x 200mm

Top:
2 x 120mm or 1 x 120mm
2 x 140mm or 1 x 140mm

Rear:
1 x 120mm,

RADIATOR SUPPORT
Front: 1 x 360mm or 1 x 240mm or 1 x 120mm
1x 280mm or 1 x 140mm

Top: 1 x 240mm or 1 x 120mm
Rear: 1 x 120mm

CLEARANCE
CPU cooler height limitation: 150mm
PSU length limitation: 160mm(With HDD Rack)
200mm(Without HDD Rack)
VGA length limitation: 300mm
RAM height limitation: 60mm(With radiator series)
