SPECIFICATION :

Model No.
SST-SX650-G

Max. DC Output
650W

Power density
819W per liter

Color
Black (Lead-Free Paint)

Combined +3.3V & +5V
110W

Combined +12V
650W

Input Voltage
90 ~ 264 Vrms

Input Frequency Range
47Hz ~ 63Hz

PFC
Active PFC (PF>0.9 at full load)

Efficiency
87%~90%（20% to 100% loading）

MTBF
100,000 hours

Operating temperature
0°C ~ 40°C

Protection
Over current protection
Over power protection
Over voltage protection
Short circuit protection
Under voltage protection

Cooling System
Single 92mm FDB silent fan

Form factor
SFX

Noise Level
18 dBA minimum

Dimension
125 mm (W) x 63.5 mm (H) x 100 mm (D)
4.92" (W) x 2.5" (H) x 3.94" (D)

Weight
1.36 kg

Certification
80 PLUS Gold

Other
GPU Support list
Compatible with ATX12V v2.4
