Spesifikasi Produk :

Key Specs
- Dimensions : W 150mm x L 140mm x H 86mm
- Material(s) : Steel, PCB and plastic
- Compliance Standard : ATX12V v2.4 / EPS12V v2.92
- AC Input Rating : 100V-240V 8A-4A 50Hz-60Hz

DC Output Rating
- Voltage : +3.3V / +5V / +5VSB /+12V / -12V
- Max Load : 20A / 20A / 2.5A / 45.5A / 0.3A
- Voltage Regulation : ±5% / ±5% / ±5% / ±5% / ±10%
- Ripple & Noise : < 50 mV p-p / < 50 mV p-p / < 50 mV p-p / < 120 mV p-p / < 120 mV p-p
- Output Power (watt) : 110 / 110 / 12.5 / 546 / 3.6
- Total : 550

Fan Specs
- Dimensions : 120 x 120 x 25 (mm)
- Speed : 2400 ±10% RPM
- Airflow : 72.90 CFM
- Noise : <44 dBA
- Bearing : FDB (Fluid Dynamic Bearing)

Energy Efficiency
- Rating : 80 Plus Bronze
- 10% loading : 82%
- 20% loading : 83%
- 50% loading : 87%
- 100% loading : 83%

Operation
- PF Correction : Active@0.96
- MTBF : 100,000 hours
- Operation Temperature : 0 to 40°C

Output Connector(s)
- 24-pin ATX Power : 1
- 8-pin CPU Power : 2
- 8-pin PCIe Power : 2
- SATA Power : 2
- Molex Power : 1

General
- Regulations & Certifications (EMC & Safety) : CB / CE / FCC / TUV / cTUV-SUDus / China CCC / Taiwan BSMI R33245/ Australia RCM / EAC / UKCA / WEEE /
- Warranty : 5 years
- Hazardous Materials : RoHS & China RoHS
