Spesifikasi Produk :.

𝗖𝗣𝗨
AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
*Refer to www.asus.com for the AMD® CPU support list.

𝗖𝗵𝗶𝗽𝘀𝗲𝘁
B550

𝗠𝗲𝗺𝗼𝗿𝘆
AMD Ryzen™ 5000 and 3000 Series Desktop Processors
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4666(O.C.)/4600(O.C.)/4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory *

AMD Ryzen™ 5000 and 4000 G-Series Processors
4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4866(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz, Un-buffered Memory *
ECC Memory (ECC mode) support varies by CPU.

𝗚𝗿𝗮𝗽𝗵𝗶𝗰𝘀
1 x DisplayPort 1.2
1 x HDMI® 2.1

𝗘𝘅𝗽𝗮𝗻𝘀𝗶𝗼𝗻 𝗦𝗹𝗼𝘁𝘀
AMD Ryzen™ 5000 and 3000 Series/ 5000 and 4000 G-Series Desktop Processors
1 x PCIe 4.0 x16 SafeSlot (supports x16 mode)
AMD B550 chipset
1 x PCIe 3.0 x16 slot (supports x4 mode)*
3 x PCIe 3.0 x1 slots

𝗦𝘁𝗼𝗿𝗮𝗴𝗲
Supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
AMD Ryzen™ 5000 and 3000 Series/ 5000 and 4000 G-Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
AMD B550 Chipset:
M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
6 x SATA 6Gb/s ports
Support RAID 0, 1, 10

𝗘𝘁𝗵𝗲𝗿𝗻𝗲𝘁
1 x Intel® 2.5Gb Ethernet
1 x Intel® I225-V 2.5Gb Ethernet
ASUS LANGuard

𝗪𝗶𝗿𝗲𝗹𝗲𝘀𝘀 & 𝗕𝗹𝘂𝗲𝘁𝗼𝗼𝘁𝗵
Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth v5.2

𝗔𝘂𝗱𝗶𝗼
ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A

𝗙𝗼𝗿𝗺 𝗙𝗮𝗰𝘁𝗼𝗿
30.5cm x 24.4cm
