Capacity

•  512GB

Form Factor

• M.2 2280

NAND Flash

• 3D TLC

Controller

• －

Dimensions (L x W x H)

• 80 x 22 x 3.5mm / 3.15 x 0.87 x 0.14inch

Weight

• 8g / 0.28oz

Interface

• PCIe Gen3x4

Sequential Read (Max)

• Up to 3500MB/s

Sequential Write (Max)

• Up to 3000MB/s

4KB Random Read IOPS(Max)

• Up to 390K

4KB Random Write IOPS(Max)

• Up to 380K

Operating temperature

• 0°C - 70°C

Storage temperature

• -40°C - 85°C

Terabytes Written (TBW)(Max Capacity*)

• 1280TB

Shock resistance

• 1500G/0.5ms

MTBF

• 2,000,000 hours

Warranty

• 5-year limited warranty
