Spesifikasi Produk :

We’re bringing back the legendary HAF Series.
HAF 500 marks the return of Cooler Masters timeless classic, the HAF series.
The HAF series features thoughtful design elements aimed to streamline user experience, and it’s designed for maximum airflow and peak performance.
A flagship HAF product is also in the works, set to break records and redefine the PC world as we know it.

Details
Product Name : HAF500
Exterior Color
Black
White
Materials Exterior : Steel, Mesh, Plastic
Left Side Panel : Tempered Glass, Steel
Dimensions (L x W x H) incl. Protrusions : 516 x 224 x 510mm

Motherboard Support : Mini-ITX, m-ATX, ATX, SSI CEB, E-ATX*
(*supports up to 12” x 12.2” motherboards, may impact cable management features)

Expansion Slots : 7
Drive Bays :
5.25“ ODD : N/A
3.5” / 2.5” Combo : 2
2.5” SSD : 2

I/O Panel USB Ports
2 x USB 3.2 Gen 1 (USB 3.0)
1x USB 3.2 Gen2 type C
Audio In / Out : 1 x single Audio jack
Other : ARGB Hub

Pre-installed Fan(s)
Front : 2 x 200mm ARGB Fans
Rear : 1 x 120mmSickleFlowARGB Fan
Top on HDD cage : 1 x 120mmSickleFlownon-led Fan

Fan Support System
Top : 3 x 120mm / 2 x 140mm / 2 x 200mm
Front : 3 x 120mm / 2 x140mm / 2 x 200mm
*200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness
Rear : 1 x 120mm
Top on HDD cage " 1 x 120mm

Radiator Support System
Top : 120/240/280/360mm
Front : 200/240/280/360mm
Rear : 120mm

Clearances
CPU Cooler : 167mm / 6.5″
Power Supply : 180mm / 7.1″
GraphicsCard : 410mm / 16.1”

Cable Routing : Behind MB Tray 30mm
Dust Filters : Top, Bottom
PSU Support : Bottommount - ATX
